StandardTestStatDistributionDemo.C File Reference

Detailed Description

StandardTestStatDistributionDemo.C

This simple script plots the sampling distribution of the profile likelihood ratio test statistic based on the input Model File. To do this one needs to specify the value of the parameter of interest that will be used for evaluating the test statistic and the value of the parameters used for generating the toy data. In this case, it uses the upper-limit estimated from the ProfileLikleihoodCalculator, which assumes the asymptotic chi-square distribution for -2 log profile likelihood ratio. Thus, the script is handy for checking to see if the asymptotic approximations are valid. To aid, that comparison, the script overlays a chi-square distribution as well. The most common parameter of interest is a parameter proportional to the signal rate, and often that has a lower-limit of 0, which breaks the standard chi-square distribution. Thus the script allows the parameter to be negative so that the overlay chi-square is the correct asymptotic distribution.


=== Using the following for ModelConfig ===
Observables:             RooArgSet:: = (obs_x_channel1,channelCat)
Parameters of Interest:  RooArgSet:: = (SigXsecOverSM)
Nuisance Parameters:     RooArgSet:: = (alpha_syst2,alpha_syst3,gamma_stat_channel1_bin_0,gamma_stat_channel1_bin_1)
Global Observables:      RooArgSet:: = (nominalLumi,nom_alpha_syst1,nom_alpha_syst2,nom_alpha_syst3,nom_gamma_stat_channel1_bin_0,nom_gamma_stat_channel1_bin_1)
PDF:                     RooSimultaneous::simPdf[ indexCat=channelCat channel1=model_channel1 ] = 0.190787

[#1] INFO:InputArguments -- The deprecated RooFit::CloneData(1) option passed to createNLL() is ignored.
[#1] INFO:Minimization -- p.d.f. provides expected number of events, including extended term in likelihood.
[#1] INFO:Minimization --  Including the following constraint terms in minimization: (alpha_syst2Constraint,alpha_syst3Constraint,gamma_stat_channel1_bin_0_constraint,gamma_stat_channel1_bin_1_constraint)
[#1] INFO:Minimization -- The following global observables have been defined and their values are taken from the model: (nominalLumi,nom_alpha_syst1,nom_alpha_syst2,nom_alpha_syst3,nom_gamma_stat_channel1_bin_0,nom_gamma_stat_channel1_bin_1)
[#1] INFO:Fitting -- RooAbsPdf::fitTo(simPdf) fixing normalization set for coefficient determination to observables in data
[#1] INFO:Fitting -- using generic CPU library compiled with no vectorizations
[#1] INFO:Fitting -- Creation of NLL object took 1.55233 ms
[#0] PROGRESS:Minimization -- ProfileLikelihoodCalcultor::DoGLobalFit - find MLE
[#1] INFO:Fitting -- RooAddition::defaultErrorLevel(nll_simPdf_obsData) Summation contains a RooNLLVar, using its error level
[#1] INFO:Minimization -- RooAbsMinimizerFcn::setOptimizeConst: activating const optimization
[#0] PROGRESS:Minimization -- ProfileLikelihoodCalcultor::DoMinimizeNLL - using Minuit2 /  with strategy 1
[#1] INFO:Minimization -- [fitFCN] No discrete parameters, performing continuous minimization only
[#1] INFO:Minimization --
  RooFitResult: minimized FCN value: 15.5775, estimated distance to minimum: 9.97883e-09
                covariance matrix quality: Full, accurate covariance matrix
                Status : MINIMIZE=0

    Floating Parameter    FinalValue +/-  Error
  --------------------  --------------------------
         SigXsecOverSM    1.1153e+00 +/-  5.87e-01
           alpha_syst2   -8.9073e-03 +/-  9.83e-01
           alpha_syst3    1.7876e-02 +/-  9.48e-01
  gamma_stat_channel1_bin_0    9.9955e-01 +/-  4.93e-02
  gamma_stat_channel1_bin_1    1.0036e+00 +/-  8.01e-02



--------------------------------------
Will generate sampling distribution at SigXsecOverSM = 2.32744
  1) 0x56319dc473f0 RooRealVar::             SigXsecOverSM = 2.32744 +/- 0.586576  L(-3 - 3)  "SigXsecOverSM"
  2) 0x56319c639bc0 RooRealVar::               alpha_syst2 = -0.634262 +/- 0.982506  L(-5 - 5)  "alpha_syst2"
  3) 0x56319db5ccb0 RooRealVar::               alpha_syst3 = -0.228416 +/- 0.947653  L(-5 - 5)  "alpha_syst3"
  4) 0x56319daecae0 RooRealVar:: gamma_stat_channel1_bin_0 = 0.969402 +/- 0.0493362  L(0 - 1.25)  "gamma_stat_channel1_bin_0"
  5) 0x56319c4042d0 RooRealVar:: gamma_stat_channel1_bin_1 = 0.954505 +/- 0.0800896  L(0 - 1.5)  "gamma_stat_channel1_bin_1"
[#0] PROGRESS:Generation -- generated toys: 500 / 1000


#include "TFile.h"
#include "TROOT.h"
#include "TH1F.h"
#include "TCanvas.h"
#include "TSystem.h"
#include "TF1.h"
#include "TSystem.h"

#include "RooWorkspace.h"
#include "RooAbsData.h"

#include "RooStats/ModelConfig.h"
#include "RooStats/FeldmanCousins.h"
#include "RooStats/ToyMCSampler.h"
#include "RooStats/PointSetInterval.h"
#include "RooStats/ConfidenceBelt.h"

#include "RooStats/ProfileLikelihoodCalculator.h"
#include "RooStats/LikelihoodInterval.h"
#include "RooStats/ProfileLikelihoodTestStat.h"
#include "RooStats/SamplingDistribution.h"
#include "RooStats/SamplingDistPlot.h"

using namespace RooFit;
using namespace RooStats;

// -------------------------------------------------------
// The actual macro

void StandardTestStatDistributionDemo(const char *infile = "", const char *workspaceName = "combined",
                                      const char *modelConfigName = "ModelConfig", const char *dataName = "obsData")
{

   // the number of toy MC used to generate the distribution
   int nToyMC = 1000;
   // The parameter below is needed for asymptotic distribution to be chi-square,
   // but set to false if your model is not numerically stable if mu<0
   bool allowNegativeMu = true;

   // -------------------------------------------------------
   // First part is just to access a user-defined file
   // or create the standard example file if it doesn't exist
   const char *filename = "";
   if (!strcmp(infile, "")) {
      filename = "results/example_combined_GaussExample_model.root";
      bool fileExist = !gSystem->AccessPathName(filename); // note opposite return code
      // if file does not exists generate with histfactory
      if (!fileExist) {
         // Normally this would be run on the command line
         cout << "will run standard hist2workspace example" << endl;
         gROOT->ProcessLine(".! prepareHistFactory .");
         gROOT->ProcessLine(".! hist2workspace config/example.xml");
         cout << "\n\n---------------------" << endl;
         cout << "Done creating example input" << endl;
         cout << "---------------------\n\n" << endl;
      }

   } else
      filename = infile;

   // Try to open the file
   TFile *file = TFile::Open(filename);

   // if input file was specified but not found, quit
   if (!file) {
      cout << "StandardRooStatsDemoMacro: Input file " << filename << " is not found" << endl;
      return;
   }

   // -------------------------------------------------------
   // Now get the data and workspace

   // get the workspace out of the file
   RooWorkspace *w = (RooWorkspace *)file->Get(workspaceName);
   if (!w) {
      cout << "workspace not found" << endl;
      return;
   }

   // get the modelConfig out of the file
   ModelConfig *mc = (ModelConfig *)w->obj(modelConfigName);

   // get the modelConfig out of the file
   RooAbsData *data = w->data(dataName);

   // make sure ingredients are found
   if (!data || !mc) {
      w->Print();
      cout << "data or ModelConfig was not found" << endl;
      return;
   }

   mc->Print();
   // -------------------------------------------------------
   // Now find the upper limit based on the asymptotic results
   RooRealVar *firstPOI = (RooRealVar *)mc->GetParametersOfInterest()->first();
   ProfileLikelihoodCalculator plc(*data, *mc);
   LikelihoodInterval *interval = plc.GetInterval();
   double plcUpperLimit = interval->UpperLimit(*firstPOI);
   delete interval;
   cout << "\n\n--------------------------------------" << endl;
   cout << "Will generate sampling distribution at " << firstPOI->GetName() << " = " << plcUpperLimit << endl;
   int nPOI = mc->GetParametersOfInterest()->getSize();
   if (nPOI > 1) {
      cout << "not sure what to do with other parameters of interest, but here are their values" << endl;
      mc->GetParametersOfInterest()->Print("v");
   }

   // -------------------------------------------------------
   // create the test stat sampler
   ProfileLikelihoodTestStat ts(*mc->GetPdf());

   // to avoid effects from boundary and simplify asymptotic comparison, set min=-max
   if (allowNegativeMu)
      firstPOI->setMin(-1 * firstPOI->getMax());

   // temporary RooArgSet
   RooArgSet poi;
   poi.add(*mc->GetParametersOfInterest());

   // create and configure the ToyMCSampler
   ToyMCSampler sampler(ts, nToyMC);
   sampler.SetPdf(*mc->GetPdf());
   sampler.SetObservables(*mc->GetObservables());
   sampler.SetGlobalObservables(*mc->GetGlobalObservables());
   if (!mc->GetPdf()->canBeExtended() && (data->numEntries() == 1)) {
      cout << "tell it to use 1 event" << endl;
      sampler.SetNEventsPerToy(1);
   }
   firstPOI->setVal(plcUpperLimit);                                  // set POI value for generation
   sampler.SetParametersForTestStat(*mc->GetParametersOfInterest()); // set POI value for evaluation

   firstPOI->setVal(plcUpperLimit);
   RooArgSet allParameters;
   allParameters.add(*mc->GetParametersOfInterest());
   allParameters.add(*mc->GetNuisanceParameters());
   allParameters.Print("v");

   SamplingDistribution *sampDist = sampler.GetSamplingDistribution(allParameters);
   SamplingDistPlot plot;
   plot.AddSamplingDistribution(sampDist);
   plot.GetTH1F(sampDist)->GetYaxis()->SetTitle(
      Form("f(-log #lambda(#mu=%.2f) | #mu=%.2f)", plcUpperLimit, plcUpperLimit));
   plot.SetAxisTitle(Form("-log #lambda(#mu=%.2f)", plcUpperLimit));

   TCanvas *c1 = new TCanvas("c1");
   c1->SetLogy();
   plot.Draw();
   double min = plot.GetTH1F(sampDist)->GetXaxis()->GetXmin();
   double max = plot.GetTH1F(sampDist)->GetXaxis()->GetXmax();

   TF1 *f = new TF1("f", Form("2*ROOT::Math::chisquared_pdf(2*x,%d,0)", nPOI), min, max);
   f->Draw("same");
   c1->SaveAs("standard_test_stat_distribution.pdf");
}

Author

Kyle Cranmer

Definition in file StandardTestStatDistributionDemo.C.
