glrose.C File Reference

Detailed Description

Render a TF2 looking like a rose.

It defines and set a user's palette, and use polar system.


void glrose()
{
   const Int_t paletteSize = 10;
   Float_t rgb[paletteSize * 3] = {0.80f, 0.55f, 0.40f, 0.85f, 0.60f, 0.45f, 0.90f, 0.65f, 0.50f, 0.95f,
                                   0.70f, 0.55f, 1.f,   0.75f, 0.60f, 1.f,   0.80f, 0.65f, 1.f,   0.85f,
                                   0.70f, 1.f,   0.90f, 0.75f, 1.f,   0.95f, 0.80f, 1.f,   1.f,   0.85f};

   Int_t palette[paletteSize] = {0};

   for (Int_t i = 0; i < paletteSize; ++i)
      palette[i] = TColor::GetColor(rgb[i * 3], rgb[i * 3 + 1], rgb[i * 3 + 2]);

   gStyle->SetPalette(paletteSize, palette);

   gStyle->SetCanvasPreferGL(1);
   TCanvas *cnv = new TCanvas("glc", "Surface sample", 200, 10, 600, 550);

   TPaveLabel *title = new TPaveLabel(0.04, 0.86, 0.96, 0.98, "\"glsurf2pol\" option + user defined palette.");
   title->SetFillColor(32);
   title->Draw();

   TPad *rosePad = new TPad("box", "box", 0.04, 0.04, 0.96, 0.8);
   rosePad->Draw();

   TF2 *fun = new TF2("a", "cos(y)*sin(x)+cos(x)*sin(y)", -6, 6, -6, 6);
   fun->SetContour(paletteSize);
   fun->SetNpx(30);
   fun->SetNpy(30);
   rosePad->cd();
   fun->Draw("glsurf2pol");
}

Author

Timur Pocheptsov

Definition in file glrose.C.
